Okuma MU-4000V 5-Axis Machining Center

5Axis Machining Center Machining Center - NC Publication Date: July 27, 2026 Print (Without Logo) Print (With Logo)

Inquire by phone

Stock ID	91243
Stock Code	0
Manufacturer	Okuma inventory List
Model Type	MU-4000V
Year	2020
Main Specifications	Control unit: OSP‑P300MA‑H Table size: φ400 mm Maximum workpiece dimensions: φ500 × H400 mm Maximum loading capacity: 300 kg Travel (X, Y, Z) : 740 x 460 x 460 mm B : +90～ –120° C : 360° Distance from spindle nose to table top: 120～580 mm Spindle taper: BBT40 (BIG‑PLUS) Spindle speed: 50～15,000 rpm Tool storage capacity: 64 tools Required floor space: 2,399 × 3,444 mm Machine height: 2,950 mm Machine weight: 9,700 kg Lift‑up chip conveyor, drum‑through type (rear discharge) X/Y/Z axis absolute scale feedback system Tool Breakage Detection and Automatic Tool Length Measurement Touch Probe for Workpiece Measurement (Renishaw) Spindle Center Through-Coolant: 1.5 MPa IMAP conversational programming Mist collector Shower cleaning system (including nozzle mounting tools) Work washing gun (drum‑through type)
Location	-
Viewing Status	Consultation
Test Run Status	Consultation
