Okuma MU-400VA 5Axis Machining Center

5Axis Machining Center Machining Center - NC Publication Date: February 13, 2025 Print (Without Logo) Print (With Logo)

Company information will be disclosed upon member registration.

Stock ID	47822
Stock Code	20301098
Manufacturer	Okuma inventory List
Model Type	MU-400VA
Year	2006
Main Specifications	◆OSP-P200M-H 3D-D MC ◆XYZ: 762×460×460 ◆A-axis: +20 to -110 degrees ◆C-axis: 360 degrees ◆Fast forward speed: XY40 Z32m/min ◆Fast forward speed: A-axis 14400 degrees/min ◆Fast forward speed: C-axis 18000 degrees/min ◆Cutting feed speed: XYZ 32m/min ◆50 to 20000min-1 ◆Tool shank shape: HSK-A63 ◆Maximum tool length: 300 ◆Table: φ400 ◆Maximum workpiece dimensions: φ400×h400 ◆ATC: 48 ◆Required floor space: W2,160×D2,715 ◆Machine height: 2,950mm ◆Weight: 7,700kg ※No touch probe ※Oil controller ※Drum filter type chip conveyor ※Through spindle coolant (medium pressure type 1.5MPa) Cutting fluid heating and cooling device Mist collector Spindle thermal displacement control TAS-S Ambient thermal displacement control TAS-C Absolute scale detection XYZ Automatic tool length compensation Including breakage detection (touch sensor) High class (simultaneous 5-axis control device) H specification DNC coupling DNC-DT Super-NURBS function Type-A (XYZAC) Fixture offset Showa Denki CRD-750R with filter ATC tool length 300L specification A/C axis swivel table: 0.001 degrees (with rotary inductosin) C-axis table: φ400 T-slot 18h7 6 pieces_If there is a difference between the specifications and the actual product, the actual product will take precedence.
Location	Mie Prefecture
Viewing Status	Consultation
Test Run Status	Consultation
