Sodick SL400G wire EDM

EDM (Wire) EDM - NC Publication Date: July 27, 2026 Print (Without Logo) Print (With Logo)

Inquire by phone

Stock ID	91244
Stock Code	0
Manufacturer	Sodick inventory List
Model Type	SL400G
Year	2014
Main Specifications	Maximum workpiece dimensions : 　　　　600 ×470 × 240 mm (jet machining) 　　　　600 ×470 × 230 mm (immersion machining) Maximum workpiece mass : 　　　　400 kg (jet machining) 　　　　350 kg (immersion machining) Machining tank internal dimensions : 850 × 610 mm Travel X : 400 Y : 300 Z : 250 mm 　　　　 U × V : 150 × 150 mm Taper machining control angle (at 80 mm thickness) : ±25° 　　　　　 Wire electrode diameter : φ0.1–φ0.3 mm Wire feed speed : 420 mm/sec Wire bobbin mass : 8 kg Required floor space : 2,115 × 2,490 mm Height : 2,230 mm Machine weight : 3,400 kg（including power supply） Service tank unit dimensions: 650 × 2,154 mm Service tank capacity: 600 liters Weight (dry): 400 kg　 Processing fluid filtration method: 3‑unit replaceable paper filter Pure water unit: 18 liters
Location	-
Viewing Status	Consultation
Test Run Status	Consultation
