Okuma MB-66VA Vertical Machining Center

Vertical Machining Center Machining Center - NC Publication Date: July 01, 2026 Print (Without Logo) Print (With Logo)

Inquire by phone

Stock ID	90382
Stock Code	00000001029
Manufacturer	Okuma inventory List
Model Type	MB-66VA
Year	2012
Main Specifications	Control unit : OSP‑P200MA Table size: 1,530 ｘ 660 mm Distance from table top to spindle nose: 150 ～ 810 mm Maximum workpiece load: 1,500 kg Travel (X / Y / Z): 1,500 × 660 × 660 mm Spindle speed: 50 ～ 15,000 rpm Tool storage capacity: 32 tools Tool shank type: BT40 MAS Pull stud type: JIS Required floor space: 2,940 x 3,265 mm Height: 3,295 mm Machine weight: 11,000 kg Spindle Head Cooling System with Oil Controller Chip Washing Coolant System Flexible Coolant Nozzles (5 units) Through‑Spindle Coolant System (Medium Pressure 1.5 MPa) No Chip Conveyor ATC Air Blow Touch Sensor Positioned at Rear‑Left Auto Tool Length & Breakage Detection (Touch Sensor) Auto Workpiece Measurement & Zero‑Point Compensation (OMP60) 　　　 No Touch Probe Door Interlock Type II (Requires Memorandum) 　　　 NC Operation Panel: 15‑inch Color TFT Work Coordinate System: 200 Sets Helical Cutting within 360° Synchronized Tapping II Tool Length & Diameter Offset: 300 Sets 　　　 Conversational Programming Function (I‑MAP) 　　　 Tool Life Management
Location	Nara Prefecture
Viewing Status	Consultation
Test Run Status	Consultation
