CNC Lathe

NC Lathe Lathe - NC Publication Date: May 18, 2026 Print (Without Logo) Print (With Logo)

Inquire by phone

Stock ID	88967
Stock Code	00000001021
Manufacturer	Okuma inventory List
Model Type	SPACE TURN LB200M
Year	2005
Main Specifications	Control unit: OKUMA OSP‑E100L Max swing: φ530 mm Swing over cross slide: φ420 mm Distance between centers: 300 mm Max work dia. × max work length: φ230× 300 mm Travel (X, Z): 180 × 335 mm C: 360° (rotational control angle 0.001°) Max spindle speed: 50～6,000 rpm Spindle through‑hole dia.: φ53 mm Turret type: 12‑station composite quick‑change type (shared for L/M) Tailstock quill travel: 80 mm Rotary Tool Speed: 100～6,000 rpm Required floor space: 2,035 × 1,720 mm Machine height: 1,700 mm Machine weight: 3,300 kg 6‑inch 3‑jaw hydraulic chuck B‑206 (Kitag Touch setter Easy conversational programming Synchronized tapping
Location	Nara Prefecture
Viewing Status	Consultation
Test Run Status	Consultation
