CNC EDM

EDM (Wire) EDM - NC Publication Date: May 11, 2026 Print (Without Logo) Print (With Logo)

AK TECHNOS CO., LTD.

050-1882-2946

Stock ID 88714
Stock Code 000000010020
Manufacturer Sodick inventory List
Model Type AG360L
Year 2013
Main Specifications

Control unit : LN1W (SI-LINK)
Maximum workpiece dimensions :
  550 × 380 × 220 mm (jet machining)
  550 × 380 × 170 mm (immersion machining)
Maximum workpiece mass :
  400 kg (jet machining)
  300 kg (immersion machining)
Machining tank internal dimensions : 894 × 720 mm
Travel X : 360 Y : 250 Z : 220 mm
    U × V : 80 × 80 mm
Taper machining control angle (at 80 mm thickness) : ±20°
Wire electrode diameter : φ0.15–φ0.3 mm
Wire feed speed : 420 mm/sec
Wire bobbin mass : 8 kg
Electrical capacity : 3-phase 50/60Hz 13 kVA

Required floor space : 1,785 × 2,260 mm
Height : 2,065 mm
Machine weight : 2,700 kg

Maximum discharge current: 40 A
Service tank unit dimensions : 800 × 2,080 × 1,895 mm
Machining fluid capacity : 590 liters
Mass (dry) (including power supply) : 585 kg
Machining fluid filtration method : Paper filter replacement type (internal pressure, dual‑cylinder type)
Eco Ion : Ion‑exchange resin (18‑liter specification)

Location Nara Prefecture
Viewing Status Consultation
Test Run Status Consultation
