NC Vertical Multitasking Lathe

NC Multi-tasking Machine Lathe - NC Publication Date: November 10, 2025 Print (Without Logo) Print (With Logo)

Okuma VTM-200YB NC Multi-tasking Machine Image 1

Okuma VTM-200YB NC Multi-tasking Machine Image 1

Attached Documents Attached Documents

AK TECHNOS CO., LTD. Image

AK TECHNOS CO., LTD.

Inquire by phone

Listed Stock List

Stock ID	81681
Stock Code	00000001005
Manufacturer	Okuma inventory List
Model Type	VTM-200YB
Year	2010
Main Specifications	Controller: FANUC-18iTB Maximum swing: φ2,400 mm Maximum machining diameter: φ2,000 mm Maximum machining length: 1,400 mm Maximum workpiece weight (including chuck weight): 7,000 kg 　　　 Cantilever support : 110 kg/ Double center support : 500 kg 　　　 Travel X: 1,600 Y: ±800 Z: 1,400 mm 　　　 B: 120° (-15° to 105°) 　　　 C: 360° (0.001° indexing) B-axis spindle NC indexing (0.001° index, 5° index combined) 　　　 Chuck rotation speed: L (low speed): 4 ～200 rpm H (high speed): 6 ～ 400 rpm 　　　 Tool rest type : H1 (1 for L (turning) and M (rotating tool)) Tool spindle speed (M-axis): 4,000 rpm Tooling: BBT50 (BIG PLUS) Magazine tool storage capacity: 36 tools Tool post type: ATC single tool Required floor space: 6,193 x 7,325 mm Height: 4,745 mm Machine weight: 35,000 kg (excluding chuck) 　　　 Controlled Axes: 5 axes (X, Y, Z, B, C) (3 axes controlled simultaneously, excluding B) 　　 φ2,000 mm 4-jaw indented chuck (jaw lock) B-axis angled indexing for turning (indexing every 5°) M-axis spindle center through coolant: 1.5 Mpa X, Y, Z, and B-axis scale feedback Automatic cutting edge measurement (automatic ATS) by Renishaw 　　　 Touch probe for workpiece measurement by Renishaw Hinged‑belt chip conveyor (left side discharge) Automatic door for workpiece removal 　　　 Tape storage capacity: 1280 m Chamfering, corner radius 　　　 Helical interpolation 　　　 Data server: 1 GB Spare M-codes: 4
Location	Nara Prefecture
Viewing Status	Consultation
Test Run Status	Consultation
