MAZAK INTEGREX300-ⅡSY（1000U） Lathe

Lathe Lathe - Manual Publication Date: March 24, 2026 Print (Without Logo) Print (With Logo)

Company information will be disclosed upon member registration.

Stock ID	86430
Stock Code	0000000114
Manufacturer	MAZAK inventory List
Model Type	INTEGREX300-ⅡSY（1000U）
Year	2004
Main Specifications	Control: MAZATROL 640MT Maximum swing: φ610 mm Swing over carriage: φ450 mm Maximum work length: 1067 mm Travel X: 580 mm Y: 230 mm Z: 1097 mm 　　　　W (sub‑spindle travel): 1100 mm 　　　　B‑axis: 225° (0.001° indexing, 5° clamp, no contouring) 　　　　　C‑axis (main and sub spindle): 360° (0.001° indexing) Spindle through‑hole diameter: φ88 mm Main and sub spindle speed: 3,500 rpm Milling tool spindle speed: 10,000 rpm Tool magazine capacity: 40 tools Required floor space: 5,820 × 2,438 mm Machine height: 2,692 mm Machine weight: 10,000 kg Equipped with sub‑spindle, maximum machining length 1067 mm 　 Main and sub spindle: 10‑inch hollow chuck (Kitagawa B‑210A0815X) 　　　 Automatic tool eye Synchronous tapping for milling spindle Turret air blow Coolant system 15K high‑pressure through‑spindle coolant and 2.4K flag coolant, 　　simultaneous discharge possible Chip conveyor (side discharge, hinge type)
Location	-
Viewing Status	Consultation
Test Run Status	Consultation
