MORI SEIKI NL2000MC/500 NC Lathe

NC Lathe Lathe - NC Publication Date: March 17, 2026 Print (Without Logo) Print (With Logo)

MORI SEIKI NL2000MC/500 NC Lathe Image 1
MORI SEIKI NL2000MC/500 NC Lathe Image 1
AK TECHNOS CO., LTD. Image
AK TECHNOS CO., LTD.
Company information will be disclosed upon member registration.
Stock ID 85985
Stock Code 00000001011
Manufacturer MORI SEIKI inventory List
Model Type NL2000MC/500
Year 2005
Main Specifications

Conroller: MSX-850
Swing over bed: 923 mm
Swing over cross slide: 755 mm
Max. turning diameter: 356 mm
Std. turning diameter: 275 mm
Max. turning length: 510 mm
Travel X: 260 Z: 590 mm
Spindle speed: 5,000 rpm
Min. indexing: C: 0.001°
Through-spindle hole diameter: φ73 mm
Spindle taper: JIS A2-6
Turret: 12 stations
Milling spindle speed: 6,000 rpm
Tailstock travel: 564 mm
Tailstock taper: MT4

Required floor space: 2,695 × 1,923 mm
Machine height: 2,120 mm
Machine weight: 5,500 kg

8"Hydraulic hollow 3-jaw chuck
Tool presetter

Location Nara
Viewing Status Consultation
Test Run Status Consultation
