Tool Grinder Grinding Machine - Manual Publication Date: February 13, 2025 Print (Without Logo) Print (With Logo)
| Stock ID | 47917 |
| Stock Code | 20606031 |
| Manufacturer | MAKINO |
| Model Type | YGR-25 |
| Year | 1986 |
| Main Specifications | ◆ Swing on the swivel table: 300mm ◆ Travel of the sliding table: 260mm ◆ Maximum machining R: 50R (Travel of the grinding wheel axis) ・Up and down movement: 180mm ・Forward and backward movement: 100mm ・Left and right movement: 350mm ・Travel angle (horizontal): 270° ・Travel angle (vertical): 270° ◆ Grinding wheel rotation speed: 3800/6500rpm ◆ Usable grinding wheels: Flat type / Slotted type / Cup type ◆ Required floor space: 1500 x 1000mm ◆ Machine height: 1590mm ◆ Weight: 600kg _If there are any differences between the specifications and the actual product, the actual product will take precedence. |
| Location | Mie Prefecture |
