NC Lathe Publication Date: February 13, 2025 Print (Without Logo) Print (With Logo)
ShinMaywa Kiko
Company information will be disclosed upon member registration.| Stock ID | 47315 |
| Stock Code | 20102090 |
| Manufacturer | MORI SEIKI inventory List |
| Model Type | NL2500Y/1250 |
| Year | 2007 |
| Main Specifications | ◆Power supply: MSX-850? ◆Swing above bed: 923.8 ◆Swing above cross slide: 755 ◆Maximum machining diameter: 366 ◆Standard machining diameter: 271 ◆Standard machining length: 1298 ◆Bar work capacity: 80 ◆Travel amount XYZ: 260×-50, +50×13445 ◆Spindle rotation speed: 4000 ◆Number of spindle speed change ranges: 2 stages ◆Spindle end: JIS A_-8 ◆Spindle through diameter: 91 ◆Minimum index angle of spindle: 0.001 ◆Spindle bearing inner diameter: 140 ◆Tool post type: 12-sided ◆Number of tools mounted on the tool post: 12 ◆Shank height of square tool: 25 ◆Diameter of shank of boring bar: 50 ◆Rotary tool spindle rotation speed: 6000min-1 ◆Rotary tool machining capacity Drill: Φ26, Tap: Max20 ◆Rapid feed speed XYZ: 30000 x 10000 x 30000 ◆Rapid feed speed tailstock: 7000 ◆Jog feed speed XYZ tailstock: 0-5000 ◆Tailstock travel distance: 1284 ◆Tailstock shaft diameter: 110 ◆Tailstock shaft tapered hole type: MT5 ◆Machine dimensions: W4339 (chip conveyor + 700) x D2143 x H2232 ◆Machine weight: 7500? _If there are any differences between the specifications and the actual product, the actual product will take precedence. |
| Location | Mie Prefecture |
| Viewing Status | Consultation |
| Test Run Status | Consultation |
